Muncie 17 GPM Pump
Muncie PK Series Hydraulic Gear Pump | Part #PK1-17-17KSBB
Power your towing and recovery equipment with commercial-grade hydraulic performance using the Genuine Muncie Power Products PK Series Hydraulic Gear Pump (Part #PK1-17-17KSBB). Built with heavy-duty cast-iron construction, this PTO-driven pump delivers high flow rates and continuous pressure output for wreckers, rollbacks, car carriers, and commercial truck hydraulic systems.
Key Features & Benefits
-
Commercial-Grade Durability: Heavy-duty, all-cast-iron housing and premium roller bearing design provide long service life under high continuous operating pressures and demanding workloads.
-
High-Displacement Fluid Delivery: Delivers nominal 17 GPM flow at 1,000 RPM, supplying reliable hydraulic energy for winches, booms, wheel lifts, and deck functions.
-
Flexible 4-Port Layout: Features straight-thread O-ring boss (O.D.T.) ports located on both the sides and rear for convenient hose routing and versatile installation.
-
Bi-Rotational Design: Standard bi-rotational capability simplifies installation and reduces inventory complexity across various PTO rotation configurations.
-
Direct PTO Drive Fitment: Engineered with a standard SAE "B" 4-bolt mounting flange and an SAE "B-B" 1.00" 15-tooth spline shaft for seamless coupling to truck PTOs.
Specifications
-
Brand: Muncie Power Products
-
Part Number: PK1-17-17KSBB (PK11717KSBB / PK1-17-17KSBBX)
-
Product Type: PTO Hydraulic Gear Pump
-
Series: Muncie PK Series
-
Flow Rate: Nominal 17 GPM @ 1,000 RPM
-
Operating Pressure: Up to 3,000 PSI MAX
-
Shaft Type: SAE "B-B" 1.00" 15-Tooth Spline
-
Mounting Flange: SAE "B" 4-Bolt Flange
-
Port Type / Location: Straight Thread O-Ring (O.D.T.); Side & Rear Ports
-
Rotation: Bi-Rotational
-
Housing Material: Heavy-Duty Cast Iron
-
Condition: Brand New OEM Replacement
