Century 1150KB 3 - Stage Boom Assembly

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Schematics Parts

	ID	Part Number	Part Name	Price	Recommended Quantity	Quantity
View Detail Miller Boom Slide Pad - Side	4	0301924	Miller Boom Slide Pad - Side	$46.04	2	- + In stock
View Detail Miller Wear Pad, 3/4" x 1" x 4"	5	0306825	Miller Wear Pad, 3/4" x 1" x 4"	$17.20	4	- + In stock
View Detail 3/8-16X3/4 HHCS GR5 ZP	8	0400121	3/8-16X3/4 HHCS GR5 ZP	$5.67	8	- + In stock
View Detail Miller 3/8" Helical Lockwasher (Zinc Plated)	13	0400482	Miller 3/8" Helical Lockwasher (Zinc Plated)	$5.67	12	Call to Order
View Detail SCREW, 5/8-11 X 1-1/2 HEX HD CAP GR8	24	9043950	SCREW, 5/8-11 X 1-1/2 HEX HD CAP GR8	$7.00	4	- + In stock
View Detail Miller Nylok Hex Nut, 3/8"-16	29	0400392	Miller Nylok Hex Nut, 3/8"-16	$6.89	4	Call to Order
View Detail Miller 3/8" Helical Lockwasher (Zinc Plated)	30	0400482	Miller 3/8" Helical Lockwasher (Zinc Plated)	$5.67	4	Call to Order
View Detail Miller SCREW, 3/8"-16 X 1-3/4" HEX HD CAP Steel 3/8" flat washer with Zinc plating	32.2	0400157	Miller SCREW, 3/8"-16 X 1-3/4" HEX HD CAP	$5.67	4	Out of stock
View Detail Miller Nylok Hex Nut, 3/8"-16	33	0400392	Miller Nylok Hex Nut, 3/8"-16	$6.89	4	Call to Order
View Detail Miller 3/8" Flat Washer Steel 3/8" flat washer with Zinc plating	34	0400480	Miller 3/8" Flat Washer	$3.89	8	Out of stock
View Detail Miller D-Ring Large Heavy Tailboard Ring	38	0719585	Miller D-Ring Large Heavy Tailboard Ring	$377.48	2	- + In stock
View Detail Miller Nylok Hex Nut, 3/8"-16	42	0400392	Miller Nylok Hex Nut, 3/8"-16	$6.89	2	Call to Order
View Detail Miller Cable Tieback Weldment - Main Boom Most common cable tie back spring used with Miller equipment 2004 and newer Use with #11-58PL pear link 9.5" in length	44	0807844	Miller Cable Tieback Weldment - Main Boom	$93.72	2	Out of stock
View Detail Miller Cable Tie Back Spring-9.5 Most common cable tie back spring used with Miller equipment 2004 and newer Use with #11-58PL pear link 9.5" in length	46	945030007	Miller Cable Tie Back Spring-9.5	$25.99	2	- + In stock
View Detail Miller D-Ring Large Heavy Tailboard Ring	57	0719585	Miller D-Ring Large Heavy Tailboard Ring	$377.48	2	- + In stock
